Brushed Pewter Oversized Fixed Panel U-Clamp

GDI Oversized Fixed Panel U-Clamp performs the same function as our Traditional Clamps. They are especially recommended for 1/2 inch (12 millimeter) thick glass installations where a hole drilling measurement of 1-1/2 times the glass thickness is required by the Temperer (from the edge of the glass to the closest edge of the hole).

For 5/16 to 1/2" (8 to 12 mm) Glass

Used to Secure Fixed Panels of Glass for Frameless Shower Enclosures

Solid Brass

A Nice Option to More Traditional U-Channel, in that the Clamps Help the Appearance of an 'All-Glass' Look

Glass Fabrication Required to Accommodate Clamps

Note: The stud that goes through the hole made in the glass is positioned further from the edge of the glass than that of the Standard U-Clamp. This makes the Oversized U-Clamp the preferred clamp of most Temperers for 1/2 inch (12 millimeter) thick glass.

Specifications:

Material: Solid Brass

Glass Thickness Range: 5/16 to 1/2 Inch (8 to 12 millimeter)

Hole Diameter Required: 5/8 to 3/4 Inch (16 to 19 millimeter)

Includes: Mounting Screw and Gaskets

Note: An Additional Set of Gaskets is Required for 5/16 Inch (8 millimeter) Glass Cat. No. UCG77 **DISCONTINUED**
